10A DC1000V Solar Diode Connector IP67 Female Male PPO

Name: 10A DC1000V Solar Diode Connector IP67 Female Male PPO
Brand: ZHEJIANG PNTECH TECHNOLOGY CO., LTD
SKU: PV004-D
Availability: InStock

Product Details

Place of Origin: China

Certification: CE/ISO9001

Model Number: PV004-D

Payment & Shipping Terms

Minimum Order Quantity: 100pcs

Price: Negotiation

Packaging Details: Bulk

Delivery Time: 3-10days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 5000pcs per day

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                    solar panel cable connectors, solar panel y connector


Product Name:	Diode Connector	Current:	10A
Connector:	Female And Male	Rated Voltage:	DC1000V
Protection Degree:	IP67	Packing:	PP Bag

Product Name:	Diode Connector
Current:	10A
Connector:	Female And Male
Rated Voltage:	DC1000V
Protection Degree:	IP67
Packing:	PP Bag

Description

10A DC1000V Solar Diode Connector IP67 Female Male PPO

Anti-Aging PV Connectors With Diode Quick Connect For Field Installation

CE New Design PPO Material Waterproof IP67 10A Solar PV Diode Connector

Product Features

Auto-lock equipment of male and female points enable easy and reliable connection
Anti-aging and UV-resistant outer cover
Popular design suitable for most field installations
Simple on-site processing
Convenient installation with strong commonality

Technical Specifications

Product Name	Diode Connector
Housing Material	PPO
Contact Material	Copper, silver plated
Pin Dimension	4.0 mm
Contact Resistance	Less than 0.5 m ohm
Application Class	Class A
Rated Voltage	TUV1500V DC/UL 600V DC
Rated Current	15A
Test Voltage	6KV (5Hz, 1Min)
Flame Class	UL94-V0
Plug Force	Less than 50N
Withdrawal Force	More than 50N
Rated Temperature	-40°C~+85°C
Upper Limited Temperature	100°C
Waterproof	IP67/IP68
Pollution Degree	2
Protection Degree	Class II
Standard	TUV
Service Life	20 years
Suitable Cable Cross Sections	2.5mm/4mm/6mm (14AWG/12AWG/10AWG) PV Wire

Assembly Instructions

During self assembly, parts and tools other than those stated by R&X are used or if the preparation and assembly instructions described here are disregarded then neither safety nor compliance with the technical data can be guaranteed.
For protection against electric shock, PV connectors must be isolated from the power supply while being assembled or disassembled.
The end product must provide protection from electric shock.
Unplugging under load: PV plug connections must not be unplugged while under load. They can be placed in a no load state by switching off the DC/AC converter or breaking the AC circuit interrupter. Plugging and unplugging while under voltage is permitted.
Disconnected connectors should be protected from dirt and water with sealing caps.
Plugged parts are watertight IP67.

Frequently Asked Questions

When can I get the quotation?

Within 24 hours of getting the inquiry. If you are very urgent to get the price, please call us to give complete specifications about the cable. Price will be calculated soon.

How long about the delivery?

Usually within 3-4 working days after payment, mainly according to the quantity.

What's your payment terms?

We accept T/T (bank transfer), L/C.

Do you accept the customized order?

Yes, we do.

Do you offer OEM & ODM?

Yes. OEM & ODM are available.
