1500VDC Solar PV Junction Box with 20A-30A Rated Current and IP65/IP68

Name: 1500VDC Solar PV Junction Box with 20A-30A Rated Current and IP65/IP68
Brand: ZHEJIANG PNTECH TECHNOLOGY CO., LTD
SKU: PNTK-GGS-001
Availability: InStock

Product Details

Place of Origin: China

Certification: CE/Rohs//ISO

Model Number: PNTK-GGS-001

Payment & Shipping Terms

Minimum Order Quantity: 100

Price: Negotiation

Packaging Details: Bulk

Delivery Time: 7-15days

Payment Terms: T/T or L/C at sight

Supply Ability: 5k per day

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    Solar Cell PV Junction Box, Solar Cell Junction Box 1500VDC, CE Certification Solar Cell Junction Box


Certifications:	CE	Application:	Solar Panel
Number Of Diodes:	1	Safety Class:	II
Hs Code:	8535900090	Rated Current:	20A/25A/30A
Wire Size Range:	12AWG / 4mm²	Cable Rated Voltage:	DC1500V

Certifications:	CE
Application:	Solar Panel
Number Of Diodes:	1
Safety Class:	II
Hs Code:	8535900090
Rated Current:	20A/25A/30A
Wire Size Range:	12AWG / 4mm²
Cable Rated Voltage:	DC1500V

Description

1500VDC Solar PV Junction Box with 20A-30A Rated Current and IP65/IP68

1500VDC Rated Voltage Solar Cell Junction Box With CE Certification And Connectors

Product Overview

The PV Junction Box is a critical component in solar panel assemblies, serving as the electrical interface that converts sunlight into usable electricity. Designed for photovoltaic (PV) modules, this junction box meets international standards (HS Code: 8535900090) and is suitable for both residential and commercial solar installations.

Key Features

Product Name: PV Junction Box
Connector Type: Female and Male
Protection Rating: IP65/IP68 (1m,1h)
Packaging: Protective Black Box
Optional Solar Connector available
Includes 1 diode for efficient power output
Tin-plated copper contact material for optimal conductivity
Designed for harsh weather conditions (-40℃ to +85℃)
1500VDC rated voltage for high-performance applications

Technical Specifications

Parameter	Specification
Contact Material	Tin Plated Copper
Certifications	CE
Temperature Range	-40℃ ~ +85℃
Protection Rating	IP65/IP68 (1m,1h)
Rated Voltage	1500VDC
Rated Current	20A/25A/30A
Wire Size Range	12AWG / 4mm²
Cable Length	30cm

Applications

This photovoltaic junction box (Model: PNTK-GGS-001) is essential for connecting solar cells within PV panels and forming complete solar arrays. Suitable for:

Residential solar installations
Commercial and industrial solar systems
Off-grid applications in remote areas
Mobile solar solutions (RVs, boats)

Ordering Information

Model Number	PNTK-GGS-001
Minimum Order Quantity	100 units
Delivery Time	7-15 days
Payment Terms	T/T or L/C at sight
Daily Production Capacity	5,000 units

Packaging & Shipping

Our PV junction boxes are securely packaged in cartons or wooden cases, sealed with protective materials. Each shipment undergoes quality inspection and includes complete product labeling. We offer multiple shipping options (air, sea, land) and handle all customs documentation for international orders.

Frequently Asked Questions

Q: What certifications does this product have?

A: CE, Rohs, and ISO certified.

Q: What is the protection rating?

A: IP65/IP68 (1m,1h) protection against dust and water immersion.

Q: Can I request custom specifications?

A: Yes, we offer customization services for bulk orders.

Q: What is the warranty policy?

A: Please contact our sales team for specific warranty information.

Note: All specifications are subject to change without prior notice. Contact our technical team for the most current product information.
