6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System

China 6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System supplier
6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System supplier 6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System supplier

Large Image :  6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System

Product Details:

Place of Origin: China
Brand Name: Pntech
Certification: TUV/UL/CE/ISO9001
Model Number: PV-A4S

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiation
Packaging Details: Bulk
Delivery Time: 3-10days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs per day
Contact Now
Detailed Product Description
Product Name: Solar Junction Box Material: PPO
Connector: MC4 Female And Male Cable Rated Voltage: DC1000V
Protection Degree: IP67 Cable Type: 2.5 4 6mm2
Power: 80-300W Color: Black



TUV UL PV-A4S 6diodes Black pv Solar Junction box IP67 for solar power system



Description:



  • With the capacity of age and UV-resistance
  • The PV-Junction box can work in the atrocious weather
  • The PV-Junction box is not only with the convenient installation of ribbon bands but also all connections are double strengthened connection;
  • The maximal working current will be changed when the box is fixed with different types of diode.
  • Standard: DIN V VDE 0126-5/05.08 UL1703

Technical parameters:



Type: PV-A4S(TUV)
Rated Voltage: 1000V DC
Contact Resistance:  less than 0.5mΩ
Protection Class:
Temperature Range: -40°C to +85°C
Wire Size Range:  2.5,4, 6mm2
Protection Degree: IP67, Closed
Insulation Material: PPO/PA, Black
Contact Material: Copper, Tin plated
Flame Class: UL94-V0



Main Speciality :



1. With the capacity of anti-aging and resistance to ultraviolet radiation on the outer cover



2. To meet the using requirement under bad outdoor condition



3. The self-locking function makes the connection mode is more convenient and firm



4. Anti electric shock insulation protection science, has good security



5. Terminals installed firmly, and convergence with good weldability



Assembly Instructions



1. During self assembly, parts and tools other than those stated by R&X are used or if the preparation and assembly instructions described here are disregarded then neither safety nor compliance with the technical data can be guaranteed.

2. For protection against electric shock, PV connectors must be isolated from the power supply while being assembled or disassembled.

3. The end product must provide protection from electric shock.

4. Unplugging under load: PV plug connections muct not be unplugged while under load. They can be placed in a no load state by switching off the DC/AC converter or breaking the AC circuit interrupter. Plugging and unplugging while under voltage is permitted.

5. Disconnected connectors should be protected from dirt and water with sealing caps.

6. Plugged parts are watertight IP67



FAQ:



1. When can I get the quotation?

Within 24 hours of getting the inquiry, if you are very urgent to get the price, please call us to give complete specifications about the cable. price will be calculated soon.

2. How long about the delivery?

Usually within 3-4 working days after payment, mainly according to the quantity.

3. What's your payment terms?

We accept T/T (bank transfer), L/C

4. Do you accept the customized order?

Yes, we do.

5. Do you offer OEM & ODM?

Yes. OEM & ODM are available.



Picture of PV junction box



6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System

6 Diodes PV Panel Junction Box DC 1000V 80 - 300W For Solar Power System
