100 Metres Tuv Single Core Solar Panel Pv Cable Wire 4mm2 for solar project

Name: 100 Metres Tuv Single Core Solar Panel Pv Cable Wire 4mm2 for solar project
Brand: ZHEJIANG PNTECH TECHNOLOGY CO., LTD
SKU: H1Z2Z2-K 1x4mm2
Availability: InStock

Product Details

Place of Origin: China

Certification: TUV/CE/ISO9001

Model Number: H1Z2Z2-K 1x4mm2

Payment & Shipping Terms

Minimum Order Quantity: 200m

Price: Negotiation

Packaging Details: 200m/roll export carton

Delivery Time: 3-10days

Payment Terms: L/C,T/T

Supply Ability: 50000m per day

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            4mm2 solar panel pv cable, 100 metres solar panel pv cable, solar pv cable 4mm2


Product Name:	Solar Panel PV Cable Wire 4mm²	Insulation:	XLPO
Packing:	100m/roll	Conductor:	Tinned Copper
Struction:	56/0.28mm	Rate Voltage:	1KV AC 1500V DC
Color:	Black And Red

Product Name:	Solar Panel PV Cable Wire 4mm²
Insulation:	XLPO
Packing:	100m/roll
Conductor:	Tinned Copper
Struction:	56/0.28mm
Rate Voltage:	1KV AC 1500V DC
Color:	Black And Red

Description

100 Metres Tuv Single Core Solar Panel Pv Cable Wire 4mm2 for solar project

100 Metres TUV Single Core Solar Panel PV Cable Wire 4mm²

Product Specifications

Attribute	Value
Product name	Solar panel PV cable wire 4mm²
Insulation	XLPO
Packing	100m/roll
Conductor	Tinned copper
Structure	56/0.28mm
Rated Voltage	1KV AC 1500V DC
Color	Black and Red

Product Description

100 metres TUV Approved Single core black and red solar panel PV cable wire 4mm². Our cable features:

UV, ozone, weather and hydrolysis resistant

Excellent oil and chemical resistance

Flame retardant (VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1)

Robust and abrasion-resistant coating

Short-circuit proof up to 200°C with double insulation

Technical Specifications

Type	Cross section	Wire struct	Conductor diameter	Outer diameter	Conductor resistance	Rated voltage	Rated current
1X4.0mm²	4	56XΦ0.285	2.6mm	5.5mm	5.09Ω/Km	1000/1800V	50A
1X6.0mm²	6	84XΦ0.285	3.3mm	6.1mm	3.39Ω/Km	1000/1800V	70A
1X10mm²	10	80XΦ0.40	4.4mm	7.2mm	2.12Ω/Km	1000/1800V	95A

Key Advantages

Dual wall insulation with electron beam cross-linking
Excellent resistance to UV, oil, greases, oxygen and ozone
Superior abrasion resistance
Halogen free, flame retardant with low toxicity
Excellent flexibility and stripping performance
High voltage and current carrying capacity
TUV approved for quality assurance

Solar cables offer exceptional durability lasting approximately 30 years, withstanding various weather conditions and temperatures while remaining ozone resistant. They provide protection against ultraviolet rays and feature low smoke emission with minimal toxicity and corrosivity in fire situations. The color-coded design enables quick identification during installation.

Packaging & Delivery

Standard Export Package: 200m/roll, 1000m/roll on pallet or wooden drum

Delivery Time: 3-10 working days after order confirmation

Shipping Options: FOB/C&F/CIF available from Ningbo or other specified ports

Frequently Asked Questions

1. When can I get the quotation?
Within 24 hours of inquiry. For urgent requests, please call with complete specifications.

2. How long is the delivery time?
Typically 3-4 working days after payment, depending on quantity.

3. What payment terms do you accept?
T/T (bank transfer) and L/C.

4. Do you accept customized orders?
Yes, we accommodate customized requirements.

5. Do you offer OEM & ODM services?
Yes, both OEM and ODM services are available.
