CE Double XLPO Insulated TUV Single Core PV Cable Wire Solar Cable 4mm2

Name: CE Double XLPO Insulated TUV Single Core PV Cable Wire Solar Cable 4mm2
Brand: ZHEJIANG PNTECH TECHNOLOGY CO., LTD
SKU: H1Z2Z2-K 1x4mm2
Availability: InStock

Product Details

Place of Origin: China

Certification: TUV/CE/ISO9001

Model Number: H1Z2Z2-K 1x4mm2

Payment & Shipping Terms

Minimum Order Quantity: 200m

Price: Negotiation

Packaging Details: 200m/roll export carton

Delivery Time: 3-10days

Payment Terms: L/C,T/T

Supply Ability: 50000m per day

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            4mm single core cable, TUV single core cable, TUV 4mm single core cable


Product Name:	Solar Cable 4mm2	Insulation:	XLPO
Packing:	200m/roll	Conductor:	Tinned Copper
Struction:	56/0.285mm	Rate Voltage:	1KV AC 1500V DC
Color:	Black And Red

Product Name:	Solar Cable 4mm2
Insulation:	XLPO
Packing:	200m/roll
Conductor:	Tinned Copper
Struction:	56/0.285mm
Rate Voltage:	1KV AC 1500V DC
Color:	Black And Red

Description

CE Double XLPO Insulated TUV Single Core PV Cable Wire Solar Cable 4mm2

CE Double XLPO Insulated TUV Single Core PV Cable Wire Solar Cable 4mm²

Product Specifications

Attribute	Value
Product name	Solar cable 4mm²
Insulation	XLPO
Packing	200m/roll
Conductor	Tinned copper
Structure	56/0.285mm
Rated Voltage	1KV AC 1500V DC
Color	Black and Red

Product Description

Single core 4mm² cable designed for high voltage solar arrays, with capacity up to 1000V DC and 55A. Features double insulation and certified by TUV, CE, and MCS standards. Ideal for ON GRID inverter systems.

Technical Details

Insulation: Halogen free cross-linked compound
Conductor: Class 5 flexible tinned copper
Current Capacity: 70A
Color: Black
Voltage Rating: 600/1000V AC & 900/1500V DC
Test Voltage: 6.5kV AC according to EN 50618

Specifications

Type	Cross section	Wire struct	Conductor diameter	Outer diameter	Conductor resistance	Rated voltage	Rated current
1X2.5mm²	2.5	48XΦ0.285	2	4.9	8.06	1000/1800	30
1X4.0mm²	4	56XΦ0.285	2.6	5.5	5.09	1000/1800	50
1X6.0mm²	6	84XΦ0.285	3.3	6.1	3.39	1000/1800	70
1X10mm²	10	80XΦ0.40	4.4	7.2	2.12	1000/1800	95

Key Advantages

Dual wall insulation with electron beam cross-linking
Excellent resistance to UV, oil, greases, oxygen and ozone
Superior abrasion resistance
Halogen free, flame retardant with low toxicity
Exceptional flexibility and stripping performance
High voltage and current carrying capacity
TUV approved for quality assurance

Solar cables offer exceptional durability with a lifespan of approximately 30 years, resistant to various weather conditions and temperatures. They provide UV protection, low smoke emission, minimal toxicity, and corrosion resistance. These cables are flame-retardant, easy to install, and environmentally friendly for recycling.

Packaging Information

Standard export package: 200m/roll or 1000m/roll on pallet or wooden drum.

Delivery Details

Delivery within 3-10 working days after order confirmation. Available shipping ports include Ningbo or other specified ports. Sea freight options: FOB, C&F, and CIF quotations available.

4mm² PV Solar Cable - Black and Red insulated solar cable on a spool
