T Type Solar Branch Connector Double Seal Rings For Better Waterproof Effect

Product Details

Place of Origin: China

Brand Name: Pntech

Certification: CE/ISO9001

Model Number: PV004-T6

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: Negotiation

Packaging Details: 100sets/polybag 500sets/carton

Delivery Time: 3-10days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 5000pairs per day

Get Best Price
Contact Now
Specifications
High Light:

solar panel branch connector

,

pv panel connectors

Product Name:
T Branch Connector Adapter
Color:
Black
Rated Voltage:
1000VDC
Protection Degree:
IP67
Rated Current::
30A
Rated Power:
4000W
Product Name:
T Branch Connector Adapter
Color:
Black
Rated Voltage:
1000VDC
Protection Degree:
IP67
Rated Current::
30A
Rated Power:
4000W
Description
T Type Solar Branch Connector Double Seal Rings For Better Waterproof Effect

Photovoltaic Solar Panel Connectors and Cables T Branch Connector Adapter



T Type Solar Branch Connector Double Seal Rings For Better Waterproof Effect 0



Y Branch parallel Connector 1 male to 6 female(M/FFFFFF) and 1 female to 6 male(F/MMMMMM)

Double seal rings for better waterproof effect. Compatible with PV cables with different insulation diameters. It can be used in harsh environment, it will survived rain, high force winds and snow



Main parameter
Product Name branch connector
voltage rating ≤DC 1000V
current rating ≤30A(3.5-6mm2)
pollution degree CAT III/2
rated power 4000W
waterproof level IP67
shell material resistance material,PP0
connecting system cromp connection
contact resistance of plug and connectors 1MΩ
testing voltage DC 6000V(50Hz,1min)
contact material copper, Ag plated
flame class UL94-VO
safety class II
suitable cable OD4.5-8.5(2.5-6.0mm2)
insertion force/withdrawal force ≤50N/≥50N
operation temperature -40ºC~+125ºC
inner material copper tin plating
certificate CE, RoHS,CCC
Contact resistence 0.4mΩ
Pin dimensions Φ4.0mm
Connecting System Crimp connection
Contact material: Copper,Tin Plated


Advantage:



1. low power loss

2. solarconnector for solar power system

3. allthe connection made by double fixed connection

4. withthe capacity of anti-aging and resistance to ultraviolet radiation on the outcover

5. withconvenient installation, strong commonality

6. to meet the using requirement under bad outdoor condition



Assembly Instructions



1. During self assembly, parts and tools other than those stated by R&X are used or if the preparation and assembly instructions described here are disregarded then neither safety nor compliance with the technical data can be guaranteed.

2. For protection against electric shock, PV connectors must be isolated from the power supply while being assembled or disassembled.

3. The end product must provide protection from electric shock.

4. Unplugging under load: PV plug connections muct not be unplugged while under load. They can be placed in a no load state by switching off the DC/AC converter or breaking the AC circuit interrupter. Plugging and unplugging while under voltage is permitted.

5. Disconnected connectors should be protected from dirt and water with sealing caps.

6. Plugged parts are watertight IP67
